Technische Daten:

Radiant Intensity

Frame rate

Microprocessor

MA6162

Operating voltage:

2.1~3.3 Vdc

power off voltage

2.0V+5%

Battery:

none

Current consumption: (Stand-by)

MAX: 18.0mA

Out Power@3V:

-9.5~ -12dBm

Baud rate :

2.9Kbps

Modulation Method

FSK

Resolution

800dpi

Number of Button/Wheel:

3 Button ,1 Wheel

Running life:

5000 Miles

Operation force in any direction:

Max:100gf

Non-operating Vibration test

passed (10 to 300Hz at 2.0G)

Operating Shock

5G 1/4 sine pulse, 11ms duration at any axis (PASS)

Non-operating shock

60G 1/4 sine wave, 11ms duration at any axis (PASS)

Operating Vibration test

passed (10 to 500Hz at 0.5G)

Microprocessor

MA6221

Power supply :

5Vdc+5%

Cable type :

USB

Model (Tx and Rx) :

No module, Designed by ourselves.

Modulation scheme/mode :

FSK

Power consumption :

900mW at operating (all led light)

Communication mode :

Simplex

Power supply :

5Vdc+5%

ID

255

System Requirement :

IBM PC compatible XP/Vista/Linux/Mac

Storage temperature :

-40~+65(℃)

Working temperature :

0-45(℃)

Length :

120 mm

Width :

60 mm

Heigh :

33 mm
